Generic photo used for illustration purposes only.

N Attenuator 3 GHz 50 Watts Bidirectional

P/N:RFHB03XXNC50
  • Average Power:50 W
  • Frequency Max:3 GHz
  • Connector:N
  • VSWR Max:1.15
  • Attenuations:1-50 dB
  • Shape:Round
  • Direction:Bidirectional
  • Dimensions (mm):79(L)*45(φ)
  • Description
    RFHB03XXNC50 from RF ONE is N type coaxial fixed attenuator operating DC to 3 GHz and rated for 50 Watts, bidirectional. Available from 1 to 50 dB. RoHS Compliant.

    For model RFHB03XXNC50, replace the XX with the desired attenuation value. Example: RFHB0330NC50 for 30 dB.
