A hybrid is a coupler that behaves as a power divider, providing an equal power split from input to output while creating a broadband 90° phase shift between the two outputs. RF ONE offer hybrid coupler in single, compact packages that provide low insertion loss, high directivity and tight coupling.
| P/N | Frequency Range | VSWR Max | IL Max | Amplitude Balance Max | Phase Balance Max | Isolation Min | Connector | Add to RFQ |
|---|---|---|---|---|---|---|---|---|
| HC00501-S | 0.5-1 GHz | 1.2 | 0.3 dB | ±0.5 dB | ±2° | 22 dB | SMA | Add to RFQ |
| HC00506-S | 0.5-6 GHz | 1.3 | 1.3 dB | ±0.7 dB | ±5° | 18 dB | SMA | Add to RFQ |
| HC00518-S | 0.5-18 GHz | 1.5 | 2.2 dB | ±1.0 dB | ±10° | 16 dB | SMA | Add to RFQ |
| HC0104-S | 1-4 GHz | 1.25 | 0.4 dB | ±0.5 dB | ±3° | 20 dB | SMA | Add to RFQ |
| HC013026-S | 1.3-2.6 GHz | 1.2 | 0.3 dB | ±0.5 dB | ±2° | 22 dB | SMA | Add to RFQ |
| HC0204-S | 2-4 GHz | 1.25 | 0.35 dB | ±0.5 dB | ±2° | 25 dB | SMA | Add to RFQ |
| HC0218-S | 2-18 GHz | 1.5 | 1.2 dB | ±0.7 dB | ±7° | 18 dB | SMA | Add to RFQ |
| HC0240-K | 2-40 GHz | 1.6 | 2.5 dB | ±1.2 dB | ±12° | 12 dB | 2.92mm | Add to RFQ |
| HC275305-K | 27.5-30.5 GHz | 1.6 | 1.8 dB | ±0.7 dB | ±10° | 15 dB | 2.92mm | Add to RFQ |
