RF ONE offers a wide range of high, medium and low power SMA coaxial fixed attenuators for RF, microwave and millimeter wave applications, power handling from 2 watts to 150 watts. The frequency range of our SMA fixed attenuators is from DC to 27 GHz. RF ONE's 27 GHz SMA coaxial fixed attenuators come in 2 watts till 50 watts, with dB values from 1 dB to 30 dB.
| P/N | Average Power | Frequency Max | VSWR Max | Attenuations | Shape | Direction | Dimensions (mm) | Add to RFQ |
|---|---|---|---|---|---|---|---|---|
| RFHB04XXSC2 | 2 W | 4 GHz | 1.2 | 1-60 dB | Round | Bidirectional | 24(L)*9(φ) | Add to RFQ |
| RFHB06XXSC2 | 2 W | 6 GHz | 1.25 | 1-60 dB | Round | Bidirectional | 24(L)*9(φ) | Add to RFQ |
| RFHB08XXSC2 | 2 W | 8.5 GHz | 1.25 | 1-60 dB | Round | Bidirectional | 24(L)*9(φ) | Add to RFQ |
| RFHB12XXSC2 | 2 W | 12.4 GHz | 1.25 | 1-60 dB | Round | Bidirectional | 24(L)*9(φ) | Add to RFQ |
| RFHB18XXSC2 | 2 W | 18 GHz | 1.3 | 0-60 dB | Round | Bidirectional | 24(L)*9(φ) | Add to RFQ |
| RFHB27XXSC2 | 2 W | 27 GHz | 1.3 | 0-30 dB | Round | Bidirectional | 16.3(L)*9(φ) | Add to RFQ |
| RFHB04XXSC2A | 2 W | 4 GHz | 1.2 | 1-60 dB | Round | Bidirectional | 27(L)*9(φ) | Add to RFQ |
| RFHB06XXSC2A | 2 W | 6 GHz | 1.25 | 1-60 dB | Round | Bidirectional | 27(L)*9(φ) | Add to RFQ |
| RFHB08XXSC2A | 2 W | 8.5 GHz | 1.25 | 1-60 dB | Round | Bidirectional | 27(L)*9(φ) | Add to RFQ |
| RFHB12XXSC2A | 2 W | 12.4 GHz | 1.25 | 1-60 dB | Round | Bidirectional | 27(L)*9(φ) | Add to RFQ |
| RFHB18XXSC2A | 2 W | 18 GHz | 1.3 | 1-60 dB | Round | Bidirectional | 27(L)*9(φ) | Add to RFQ |
| RFHB27XXSC2A | 2 W | 27 GHz | 1.3 | 1-30 dB | Round | Bidirectional | 21.8(L)*9(φ) | Add to RFQ |
| RFHB04XXSC5 | 5 W | 4 GHz | 1.1 | 1-60 dB | Round | Bidirectional | 9(L)*19(φ) | Add to RFQ |
| RFHB06XXSC5 | 5 W | 6 GHz | 1.15 | 1-60 dB | Round | Bidirectional | 9(L)*19(φ) | Add to RFQ |
| RFHB08XXSC5 | 5 W | 8.5 GHz | 1.15 | 1-60 dB | Round | Bidirectional | 9(L)*19(φ) | Add to RFQ |
| RFHB12XXSC5 | 5 W | 12.4 GHz | 1.2 | 1-60 dB | Round | Bidirectional | 9(L)*19(φ) | Add to RFQ |
| RFHB18XXSC5 | 5 W | 18 GHz | 1.25 | 1-60 dB | Round | Bidirectional | 9(L)*19(φ) | Add to RFQ |
| RFHB27XXSC5 | 5 W | 27 GHz | 1.3 | 1-60 dB | Round | Bidirectional | 9(L)*19(φ) | Add to RFQ |
| RFHB04XXSC10 | 10 W | 4 GHz | 1.15 | 1-40 dB | Round | Bidirectional | 28(L)*15.8(φ) | Add to RFQ |
| RFHB06XXSC10 | 10 W | 6 GHz | 1.2 | 1-40 dB | Round | Bidirectional | 28(L)*15.8(φ) | Add to RFQ |
| RFHB08XXSC10 | 10 W | 8.5 GHz | 1.2 | 1-40 dB | Round | Bidirectional | 28(L)*15.8(φ) | Add to RFQ |
| RFHB12XXSC10 | 10 W | 12.4 GHz | 1.25 | 1-40 dB | Round | Bidirectional | 28(L)*15.8(φ) | Add to RFQ |
| RFHB18XXSC10 | 10 W | 18 GHz | 1.35 | 1-40 dB | Round | Bidirectional | 28(L)*15.8(φ) | Add to RFQ |
| RFHB04XXSC15 | 15 W | 4 GHz | 1.2 | 1-40 dB | Round | Bidirectional | 34(L)*15.8(φ) | Add to RFQ |
| RFHB06XXSC15 | 15 W | 6 GHz | 1.25 | 1-40 dB | Round | Bidirectional | 34(L)*15.8(φ) | Add to RFQ |
| RFHB08XXSC15 | 15 W | 8.5 GHz | 1.25 | 1-40 dB | Round | Bidirectional | 34(L)*15.8(φ) | Add to RFQ |
| RFHB12XXSC15 | 15 W | 12.4 GHz | 1.35 | 1-40 dB | Round | Bidirectional | 34(L)*15.8(φ) | Add to RFQ |
| RFHB18XXSC15 | 15 W | 18 GHz | 1.45 | 1-40 dB | Round | Bidirectional | 34(L)*15.8(φ) | Add to RFQ |
| RFHB04XXSC20 | 20 W | 4 GHz | 1.15 | 1-40 dB | Round | Bidirectional | 40(L)*38(φ) | Add to RFQ |
| RFHB06XXSC20 | 20 W | 6 GHz | 1.2 | 1-40 dB | Round | Bidirectional | 40(L)*38(φ) | Add to RFQ |
| RFHB08XXSC20 | 20 W | 8.5 GHz | 1.2 | 1-40 dB | Round | Bidirectional | 40(L)*38(φ) | Add to RFQ |
| RFHB12XXSC20 | 20 W | 12.4 GHz | 1.25 | 1-40 dB | Round | Bidirectional | 40(L)*38(φ) | Add to RFQ |
| RFHB18XXSC20 | 20 W | 18 GHz | 1.35 | 1-40 dB | Round | Bidirectional | 40(L)*38(φ) | Add to RFQ |
| RFHB18XXSC20-A | 20 W | 18 GHz | 1.45 | 1-40 dB | Round | Bidirectional | 49.5(L)*30(φ) | Add to RFQ |
| RFH04XXSD20 | 20 W | 4 GHz | 1.2 | 1-40 dB | Round | Unidirectional | 54(L)*15(φ) | Add to RFQ |
| RFH06XXSD20 | 20 W | 6 GHz | 1.25 | 1-40 dB | Round | Unidirectional | 54(L)*15(φ) | Add to RFQ |
| RFH08XXSD20 | 20 W | 8.5 GHz | 1.25 | 1-40 dB | Round | Unidirectional | 54(L)*15(φ) | Add to RFQ |
| RFH12XXSD20 | 20 W | 12.4 GHz | 1.35 | 1-40 dB | Round | Unidirectional | 54(L)*15(φ) | Add to RFQ |
| RFH18XXSD20 | 20 W | 18 GHz | 1.45 | 1-40 dB | Round | Unidirectional | 54(L)*15(φ) | Add to RFQ |
| RFHB04XXSC25 | 25 W | 4 GHz | 1.15 | 1-40 dB | Round | Bidirectional | 40(L)*38(φ) | Add to RFQ |
| RFHB06XXSC25 | 25 W | 6 GHz | 1.2 | 1-40 dB | Round | Bidirectional | 40(L)*38(φ) | Add to RFQ |
| RFHB08XXSC25 | 25 W | 8.5 GHz | 1.2 | 1-40 dB | Round | Bidirectional | 40(L)*38(φ) | Add to RFQ |
| RFHB12XXSC25 | 25 W | 12.4 GHz | 1.25 | 1-40 dB | Round | Bidirectional | 40(L)*38(φ) | Add to RFQ |
| RFHB18XXSC25 | 25 W | 18 GHz | 1.35 | 1-40 dB | Round | Bidirectional | 40(L)*38(φ) | Add to RFQ |
| RFH04XXSD30 | 30 W | 4 GHz | 1.2 | 1-60 dB | Round | Unidirectional | 85.8(L)*15(φ) | Add to RFQ |
| RFH06XXSD30 | 30 W | 6 GHz | 1.25 | 1-60 dB | Round | Unidirectional | 85.8(L)*15(φ) | Add to RFQ |
| RFH08XXSD30 | 30 W | 8.5 GHz | 1.25 | 1-60 dB | Round | Unidirectional | 85.8(L)*15(φ) | Add to RFQ |
| RFH12XXSD30 | 30 W | 12.4 GHz | 1.3 | 1-60 dB | Round | Unidirectional | 85.8(L)*15(φ) | Add to RFQ |
| RFH18XXSD30 | 30 W | 18 GHz | 1.35 | 1-60 dB | Round | Unidirectional | 85.8(L)*15(φ) | Add to RFQ |
| RFH04XXSA50 | 50 W | 4 GHz | 1.25 | 1-40 dB | Round | Unidirectional | 70(L)*38(φ) | Add to RFQ |
| RFH06XXSA50 | 50 W | 6 GHz | 1.25 | 1-40 dB | Round | Unidirectional | 70(L)*38(φ) | Add to RFQ |
| RFH08XXSA50 | 50 W | 8.5 GHz | 1.3 | 1-40 dB | Round | Unidirectional | 70(L)*38(φ) | Add to RFQ |
| RFH12XXSA50 | 50 W | 12.4 GHz | 1.35 | 1-40 dB | Round | Unidirectional | 70(L)*38(φ) | Add to RFQ |
| RFH18XXSA50 | 50 W | 18 GHz | 1.45 | 1-40 dB | Round | Unidirectional | 70(L)*38(φ) | Add to RFQ |
| RFHB04XXSC50 | 50 W | 4 GHz | 1.2 | 1-50 dB | Round | Bidirectional | 70*64(φ) | Add to RFQ |
| RFHB06XXSC50 | 50 W | 6 GHz | 1.25 | 1-50 dB | Round | Bidirectional | 70*64(φ) | Add to RFQ |
| RFHB08XXSC50 | 50 W | 8.5 GHz | 1.25 | 1-50 dB | Round | Bidirectional | 70*64(φ) | Add to RFQ |
| RFHB12XXSC50 | 50 W | 12.4 GHz | 1.35 | 1-50 dB | Round | Bidirectional | 70*64(φ) | Add to RFQ |
| RFHB18XXSC50 | 50 W | 18 GHz | 1.45 | 1-50 dB | Round | Bidirectional | 70*64(φ) | Add to RFQ |
| RFHB04XXSC50-S | 50 W | 4 GHz | 1.15 | 3-40 dB | Square | Bidirectional | 70*64*64 | Add to RFQ |
| RFHB06XXSC50-S | 50 W | 6 GHz | 1.2 | 3-40 dB | Square | Bidirectional | 70*64*64 | Add to RFQ |
| RFHB08XXSC50-S | 50 W | 8.5 GHz | 1.2 | 3-40 dB | Square | Bidirectional | 70*64*64 | Add to RFQ |
| RFHB12XXSC50-S | 50 W | 12.4 GHz | 1.25 | 3-40 dB | Square | Bidirectional | 70*64*64 | Add to RFQ |
| RFHB18XXSC50-S | 50 W | 18 GHz | 1.35 | 3-40 dB | Square | Bidirectional | 70*64*64 | Add to RFQ |
| RFH04XXSD50-D | 50 W | 4 GHz | 1.2 | 1-50 dB | Rectangular | Unidirectional | 70*110*120 | Add to RFQ |
| RFH06XXSD50-D | 50 W | 6 GHz | 1.25 | 1-50 dB | Rectangular | Unidirectional | 70*110*120 | Add to RFQ |
| RFH08XXSD50-D | 50 W | 8.5 GHz | 1.25 | 1-50 dB | Rectangular | Unidirectional | 70*110*120 | Add to RFQ |
| RFH12XXSD50-D | 50 W | 12.4 GHz | 1.35 | 1-50 dB | Rectangular | Unidirectional | 70*110*120 | Add to RFQ |
| RFH18XXSD50-D | 50 W | 18 GHz | 1.45 | 1-50 dB | Rectangular | Unidirectional | 70*110*120 | Add to RFQ |
| RFH27XXSD50 | 50 W | 27 GHz | 1.3 | 10-30 dB | Round | Unidirectional | 88.8(L)*54(φ) | Add to RFQ |
| RFHB04XXSC75 | 75 W | 4 GHz | 1.2 | 6-60 dB | Round | Bidirectional | 121(L)*64(φ) | Add to RFQ |
| RFHB06XXSC75 | 75 W | 6 GHz | 1.25 | 6-60 dB | Round | Bidirectional | 121(L)*64(φ) | Add to RFQ |
| RFHB08XXSC75 | 75 W | 8.5 GHz | 1.25 | 6-60 dB | Round | Bidirectional | 121(L)*64(φ) | Add to RFQ |
| RFHB12XXSC75 | 75 W | 12.4 GHz | 1.35 | 6-60 dB | Round | Bidirectional | 121(L)*64(φ) | Add to RFQ |
| RFHB18XXSC75 | 75 W | 18 GHz | 1.45 | 6-60 dB | Round | Bidirectional | 121(L)*64(φ) | Add to RFQ |
| RFHB04XXSC75-S | 75 W | 4 GHz | 1.2 | 6-60 dB | Square | Bidirectional | 105*64*64 | Add to RFQ |
| RFHB06XXSC75-S | 75 W | 6 GHz | 1.25 | 6-60 dB | Square | Bidirectional | 105*64*64 | Add to RFQ |
| RFHB08XXSC75-S | 75 W | 8.5 GHz | 1.25 | 6-60 dB | Square | Bidirectional | 105*64*64 | Add to RFQ |
| RFHB12XXSC75-S | 75 W | 12.4 GHz | 1.35 | 6-60 dB | Square | Bidirectional | 105*64*64 | Add to RFQ |
| RFHB18XXSC75-S | 75 W | 18 GHz | 1.45 | 6-60 dB | Square | Bidirectional | 105*64*64 | Add to RFQ |
| RFHB04XXSC100 | 100 W | 4 GHz | 1.2 | 6-60 dB | Round | Bidirectional | 121(L)*64(φ) | Add to RFQ |
| RFHB06XXSC100 | 100 W | 6 GHz | 1.25 | 6-60 dB | Round | Bidirectional | 121(L)*64(φ) | Add to RFQ |
| RFHB08XXSC100 | 100 W | 8.5 GHz | 1.25 | 6-60 dB | Round | Bidirectional | 121(L)*64(φ) | Add to RFQ |
| RFHB12XXSC100 | 100 W | 12.4 GHz | 1.35 | 6-60 dB | Round | Bidirectional | 121(L)*64(φ) | Add to RFQ |
| RFHB18XXSC100 | 100 W | 18 GHz | 1.45 | 6-60 dB | Round | Bidirectional | 121(L)*64(φ) | Add to RFQ |
| RFHB03XXSA100-D | 100 W | 3 GHz | 1.25 | 6-60 dB | Rectangular | Bidirectional | 101*110*120 | Add to RFQ |
| RFHB06XXSA100-D | 100 W | 6 GHz | 1.25 | 6-60 dB | Rectangular | Bidirectional | 101*110*120 | Add to RFQ |
| RFHB08XXSA100-D | 100 W | 8.5 GHz | 1.25 | 6-60 dB | Rectangular | Bidirectional | 101*110*120 | Add to RFQ |
| RFHB12XXSA100-D | 100 W | 12.4 GHz | 1.35 | 6-60 dB | Rectangular | Bidirectional | 101*110*120 | Add to RFQ |
| RFHB18XXSA100-D | 100 W | 18 GHz | 1.45 | 6-60 dB | Rectangular | Bidirectional | 101*110*120 | Add to RFQ |
| RFH04XXSD100 | 100 W | 4 GHz | 1.2 | 6-60 dB | Round | Unidirectional | 121(L)*64(φ) | Add to RFQ |
| RFH06XXSD100 | 100 W | 6 GHz | 1.25 | 6-60 dB | Round | Unidirectional | 121(L)*64(φ) | Add to RFQ |
| RFH08XXSD100 | 100 W | 8.5 GHz | 1.25 | 6-60 dB | Round | Unidirectional | 121(L)*64(φ) | Add to RFQ |
| RFH12XXSD100 | 100 W | 12.4 GHz | 1.35 | 6-60 dB | Round | Unidirectional | 121(L)*64(φ) | Add to RFQ |
| RFH18XXSD100 | 100 W | 18 GHz | 1.45 | 6-60 dB | Round | Unidirectional | 121(L)*64(φ) | Add to RFQ |
| RFH04XXSD100-D | 100 W | 4 GHz | 1.2 | 6-60 dB | Rectangular | Unidirectional | 101*110*120 | Add to RFQ |
| RFH06XXSD100-D | 100 W | 6 GHz | 1.25 | 6-60 dB | Rectangular | Unidirectional | 101*110*120 | Add to RFQ |
| RFH08XXSD100-D | 100 W | 8.5 GHz | 1.25 | 6-60 dB | Rectangular | Unidirectional | 101*110*120 | Add to RFQ |
| RFH12XXSD100-D | 100 W | 12.4 GHz | 1.35 | 6-60 dB | Rectangular | Unidirectional | 101*110*120 | Add to RFQ |
| RFH18XXSD100-D | 100 W | 18 GHz | 1.45 | 6-60 dB | Rectangular | Unidirectional | 101*110*120 | Add to RFQ |
