Generic photo used for illustration purposes only.

N Attenuator 4 GHz 25 Watts

P/N:RFHB04XXNC25
  • Average Power:25 W
  • Frequency Max:4 GHz
  • Connector:N
  • VSWR Max:1.2
  • Attenuations:1-50 dB
  • Shape:Round
  • Direction:Bidirectional
  • Dimensions (mm):49.5(L)*38(φ)
  • Description
    RFHB04XXNC25 from RF ONE is N type coaxial fixed attenuator operating DC to 4 GHz and rated for 25 Watts, bidirectional. Available from 1 to 50 dB. RoHS Compliant.

    For model RFHB04XXNC25, replace the XX with the desired attenuation value. Example: RFHB0430NC25 for 30 dB.
