Generic photo used for illustration purposes only.

TNC Attenuator 4 GHz 5 Watts

P/N:RFHB04XXTC5
  • Average Power:5 W
  • Frequency Max:4 GHz
  • Connector:TNC
  • VSWR Max:1.2
  • Attenuations:1-40 dB
  • Shape:Round
  • Direction:Bidirectional
  • Dimensions (mm):49.5(L)*25(φ)
  • Description
    RFHB04XXTC5 from RF ONE is TNC coaxial fixed attenuator operating DC to 4 GHz and rated for 5 Watts, bidirectional. Available from 1 to 40 dB. RoHS Compliant.

    For model RFHB04XXTC5, replace the XX with the desired attenuation value. Example: RFHB0430TC5 for 30 dB.
