Generic photo used for illustration purposes only.

WR19 Waveguide Crossguide Coupler, 40 dB, 39.2-59.6 GHz, 1.85mm Female Coupled Port

P/N:WDCT19185F-40
  • Series:Crossguide
  • Waveguide Size:WR19
  • Frequency Range:39.2-59.6 GHz
  • Coupling Port:1.85mm Female
  • Coupling:40 dB
  • Directivity Min:15 dB
  • Description
    WDCT19185F-40 from RF ONE is a 40 dB WR19 three port crossguide directional coupler with intergrated 1.85mm female connector for the coupled port. This waveguide crossguide directional coupler has a 40 dB nominal coupling level and 15 dB min directivity across the full waveguide band from 39.2 to 59.6 GHz. The compactness of the crossguide coupler suits many applications when space is a premium consideration while directivity is not critical. Custom designs available.
